OBD-II Scanner -- EZ-SCAN5

	USB interface		Bluetooth interface
	Larger view		Larger view
USB interface   Bluetooth interface   Use genuine ELM Chip Easy installation Easy operation Supporting current all 5 kinds of OBD-II protocals Automatic protocol detection Installing as a virtual COM port on any USB compatible     computer Compact firm factor Compatible with a number of software applications     (include freewares & commercial softwares) Bundle Digimoto 5.x software (option)   Use genuine ELM Chip Easy installation Easy operation Supporting current all 5 kinds of OBD-II protocals Automatic protocol detection Installing as a bluetooth virtual COM port Compact firm factor Compatible with a number of software applications    (include freewares & commercial softwares) Bundle Digimoto 5.x software (option)
USB interface   Bluetooth interface   Processor : Genuine ELM327 Chip   Processor : Genuine ELM327 Chip   OBD-II Protocols : ISO15765-4 (CAN) ISO14230-4 (KWP2000) ISO9141-2 J1850 VPW J1850 PWM   OBD-II Protocols : ISO15765-4 (CAN) ISO14230-4 (KWP2000) ISO9141-2 J1850 VPW J1850 PWM   Output protocol: USB, Virtual COM port   Output protocol: Bluetooth COM port   Operating voltage: 12V   Operating voltage: 12V   Indicator LEDs: Power(Green LED), OBD Tx/Rx(Yellow LED), RS232 Tx/Rx (Yellow LED)   Indicator LEDs: Power(Green LED), OBD Tx/Rx(Yellow LED), RS232 Tx/Rx (Yellow LED) Bluetooth (Blue LED)   Dimensions: 94 mm x 50mm x 33 mm   Dimensions: 94 mm x 50mm x 33 mm
USB interface   Bluetooth interface   EZ-SCAN5 Unit OBD-II Cable USB Cable Free software CD User's manual White box (L23.2cmXW15cmXH5.1cm) Option: Digimoto software CD   EZ-SCAN5 Unit OBD-II Cable Free software CD User's manual White box (L23.2cmXW15cmXH5.1cm) Option: Digimoto software CD               EZ-SCAN5 USB interface  US$139.0   EZ-SCAN5 Bluetooth interface  US$179.0           Buy EZ-SCAN5 USB interface   Buy EZ-SCAN5 Bluetooth interface   2CheckOut.com Inc. (Ohio, USA) is an authorized retailer for goods and services provided by EZ Walker Information Co., Ltd..   2CheckOut.com Inc. (Ohio, USA) is an authorized retailer for goods and services provided by EZ Walker Information Co., Ltd..
